Feature:
1, Optical distribution tray is used at optical access network terminal. It acts as the optical distribution and fusion
2, Box body is made of metal material. It looks nice in shape and its operation is convenient, anti-ageing and corrosion can be assured by the adoption of SMC compound materials
3, The sealing performance meets the IP65-level requirement of GB4208 standard, thus, it is suitable for outdoor distribution
4, It is the combination of three functions: Optical fusion, store and distribution
5, Fusion tray can be turned over, also can be pulled out to operate outside the box, the expansion of capacity is easy
6, Adapter is installed with a certain angel, maintenance is easy, transmission loss is low
7, It suits to common optical fiber cable, also to band optical fiber cable's fusion
8, Designed by full modulation, unit box has functions as optical fiber fusion, tray storing and distribution, each fusion module can be singly taken out to meet the demands for operating frame
9, Optical cable, pigtail fiber and patch cord can be clearly monitored, convenient operation can still be guaranteed even though the capacity has reached its maximum
10, Such adapters as FC, SC, ST, LC etc. Can be installed by the fusion module
11, Working temperature: -5~+40 centigrade
12, Relative humidity: <=85%(30)
13, Air pressure: 70~106Kpa
14, Standard working wavelength: 850, 1310, 1550nm
15, Connector loss: <=0.5db
16, Back wave loss: PC>=40dB, UPC>=50dB, APC>=60dB
17, Life: 1000 times
18, 19" standard frame and complete front operations
